The most powerful LightWELD system — built for the thickest materials and the heaviest fabrication work. 2,000W continuous, 3,000W peak pulse.
LightWELD 2000 XR — 2,000W maximum power handheld laser welding system, 3,000W peak pulse. Welds steel/aluminium to 8mm, titanium to 7mm. AS3820 compliant.
| Laser Power | Up to 2,000 W |
| Peak Pulse Power | Up to 3,000 W |
| Steel / Al 3&5 Series | Up to 8 mm |
| Aluminium 6 Series | Up to 5 mm |
| Titanium & Nickel | Up to 7 mm |
| Copper | Up to 3 mm |
| Cleaning Width | Up to 15 mm |
| Preset Modes | 100 |
| Power Supply | 220V, 33A |
| Weight | 60 kg |
Up to 8mm on steel and aluminium — a 26% increase over the 1500 XR — plus 7mm titanium and nickel, 3mm copper.
The largest preset library in the range, tuned for the heaviest material combinations LightWELD can handle.
100% duty cycle at full rated power — designed for all-day industrial use, including demanding Australian summer workshop conditions.
The 2000 XR is the most powerful LightWELD — 33% more continuous power and 3,000W peak pulse for the thickest materials.
| Specification | LightWELD 1500 XR | LightWELD 2000 XR |
|---|---|---|
| Laser Power | Up to 1,500 W | Up to 2,000 W |
| Peak Pulse Power | Up to 2,500 W | Up to 3,000 W |
| Steel & Stainless | Up to 6.35 mm | Up to 8 mm |
| Titanium & Nickel Alloys | Up to 5 mm | Up to 7 mm |
| Copper | Up to 2 mm | Up to 3 mm |
| Preset Modes | 74 | 100 |
| Power Supply | 220V, 24A | 220V, 33A |
| Weight | 53 kg | 60 kg |
Speak with our Hallam, Victoria team about specification, power supply requirements, and live demonstrations.
